| Overall dimensions（mm) | Rated load(KN) | Rated load{kgf} | Rated speed min-1 | Bearing code | Installation dimensions(mm) | constant | Axial load Coefficient | Weight(kg) | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | γ(minimum) | Cr | Cor | Cr | Cor | Grease lubrication | Oil lubrication | Cylindrical hole | Conical hole | da（minimum） | da(maximum） | da(maximum） | da（minimum） | γa（maximum） | e | Y2 | Y3 | Y0 | (Reference) |
| 1400 | 1950 | 545 | 12 | 24500 | 65000 | 2500000 | 6650000 | 60 | 75 | 240/1400CA E4 | 240/1400CA K30E4 | 1454 | — | 1896 | 1767 | 10 | 0.25 | 4 | 2.7 | 2.6 | 4900 |
| 1400 | 1820 | 315 | 9.5 | 14300 | 40500 | 1460000 | 4100000 | 80 | 100 | 239/1400CA E4 | 239/1400CA KE4 | 1444 | — | 1776 | 1703 | 8 | 0.16 | 6.5 | 4.3 | 4.2 | 2140 |
| 1370 | 1780 | 265 | 9.5 | 11900 | 31500 | 1210000 | 3250000 | 67 | 90 | — | 1370SL1761KE4 | 1414 | — | 1736 | 1675 | 8 | 0.13 | 7.7 | 5.1 | 5 | 1650 |
| 1320 | 1850 | 530 | 12 | 22600 | 63500 | 2310000 | 6500000 | 67 | 85 | 240/1320CA E4 | 240/1320CA K30E4 | 1374 | — | 1796 | 1656 | 10 | 0.26 | 3.9 | 2.6 | 2.6 | 4400 |
| 1250 | 1750 | 500 | 9.5 | 21000 | 59500 | 2140000 | 6050000 | 75 | 100 | 240/1250CA E4 | 240/1250CA K30E4 | 1294 | — | 1706 | 1579 | 8 | 0.25 | 4 | 2.7 | 2.6 | 3700 |
| 1250 | 1630 | 280 | 7.5 | 11600 | 31500 | 1180000 | 3200000 | 100 | 120 | 239/1250CA E4 | 239/1250CA KE4 | 1286 | — | 1594 | 1526 | 6 | 0.15 | 6.6 | 4.4 | 4.3 | 1540 |
| 1180 | 1660 | 475 | 9.5 | 20200 | 52500 | 2060000 | 5350000 | 85 | 110 | 240/1180CA E4 | 240/1180CA K30E4 | 1224 | — | 1616 | 1494 | 8 | 0.27 | 3.7 | 2.5 | 2.4 | 3180 |
| 1120 | 1580 | 462 | 9.5 | 18700 | 49500 | 1910000 | 5050000 | 95 | 120 | 240/1120CA E4 | 240/1120CA K30E4 | 1164 | — | 1536 | 1421 | 8 | 0.27 | 3.7 | 2.5 | 2.5 | 2790 |
| 1120 | 1580 | 380 | 9.5 | 15500 | 38500 | 1580000 | 3950000 | 110 | 140 | 1120SL1561E4 | — | 1164 | — | 1536 | 1435 | 8 | 0.21 | 4.8 | 3.2 | 3.2 | 2330 |
| 1120 | 1580 | 345 | 9.5 | 15400 | 38000 | 1570000 | 3850000 | 110 | 140 | 230/1120CA E4 | 230/1120CA KE4 | 1164 | — | 1536 | 1444 | 8 | 0.2 | 5 | 3.4 | 3.3 | 2120 |
| 1120 | 1460 | 250 | 7.5 | 9500 | 26000 | 970000 | 2650000 | 120 | 150 | 239/1120CA E4 | 239/1120CA KE4 | 1156 | — | 1424 | 1365 | 6 | 0.15 | 6.6 | 4.4 | 4.3 | 1100 |
| 1060 | 1500 | 438 | 9.5 | 16800 | 43000 | 1720000 | 4350000 | 100 | 130 | 240/1060CA E4 | 240/1060CA K30E4 | 1104 | — | 1456 | 1346 | 8 | 0.28 | 3.6 | 2.4 | 2.4 | 2410 |
| 1060 | 1500 | 325 | 9.5 | 13000 | 31500 | 1330000 | 3200000 | 120 | 160 | 230/1060CA E4 | 230/1060CA KE4 | 1104 | — | 1456 | 1368 | 8 | 0.21 | 4.9 | 3.3 | 3.2 | 1790 |
| 1060 | 1400 | 250 | 7.5 | 9300 | 24400 | 950000 | 2490000 | 130 | 170 | 239/1060CA E4 | 239/1060CA KE4 | 1096 | — | 1364 | 1302 | 6 | 0.16 | 6.1 | 4.1 | 4 | 1030 |
| 1000 | 1420 | 412 | 7.5 | 15300 | 38500 | 1560000 | 3950000 | 110 | 150 | 240/1000CA E4 | 240/1000CA K30E4 | 1036 | — | 1384 | 1275 | 6 | 0.27 | 3.7 | 2.5 | 2.4 | 2010 |
| 1000 | 1420 | 308 | 7.5 | 11900 | 28100 | 1210000 | 2860000 | 140 | 170 | 230/1000CA E4 | 230/1000CA KE4 | 1036 | — | 1384 | 1298 | 6 | 0.2 | 4.9 | 3.3 | 3.2 | 1560 |
| 1000 | 1320 | 236 | 7.5 | 8200 | 21700 | 835000 | 2210000 | 150 | 190 | 239/1000CA E4 | 239/1000CA KE4 | 1036 | — | 1284 | 1229 | 6 | 0.16 | 6.4 | 4.3 | 4.2 | 881 |
| 950 | 1660 | 530 | 15 | 24700 | 50500 | 2520000 | 5150000 | 100 | 130 | 232/950CA E4 | 232/950CA KE4 | 1014 | — | 1596 | 1428 | 12 | 0.32 | 3.1 | 2.1 | 2.1 | 4800 |
| 950 | 1360 | 412 | 7.5 | 14500 | 36500 | 1480000 | 3700000 | 120 | 160 | 240/950CA E4 | 240/950CA K30E4 | 986 | — | 1324 | 1219 | 6 | 0.28 | 3.6 | 2.4 | 2.3 | 1880 |
| 950 | 1360 | 300 | 7.5 | 11300 | 26500 | 1160000 | 2710000 | 150 | 190 | 230/950CA E4 | 230/950CA KE4 | 986 | — | 1324 | 1241 | 6 | 0.21 | 4.8 | 3.2 | 3.2 | 1400 |
