Slide block seat

Triple-sealed insert bearing unit

Slide block seat

Back

Sliding-type bearings consist of a spherical roller bearing combined with a sliding housing. Featuring an integrated sliding guide mechanism, they allow for flexible positional adjustment on the mounting surface, facilitating the tensioning and alignment compensation of transmission mechanisms such as belts and chains. These bearings possess self-aligning properties, effectively compensating for installation misalignment and shaft deflection. They are simple to install and secure, offer stable load-bearing capacity and excellent sealing performance, and are widely used in conveyors, textile machinery, fans and various types of transmission equipment requiring clearance adjustment. They serve as practical support components in applications with complex operating conditions and limited installation space.

shaft diameter(mm)	Bearing unit type number	Main dimensions(mm)															Type number	Bearing		Bearing seat nominal type number	Weight of bearing with seat (kg)
		Main dimensions(mm)																Basic Rated Load(kN)
		A	A₁	A₂	H	H₁	H₂	L	L₁	L₂	L₃	N	N₁	N₂	B	S		Cr	Cor
65	UCT213RT	70	26	44	167	151	111	224	137	21	121	41	32	70	65.1	25.4	UC213RT	57.5	40	T213	7
60	UCT212RT	64	22	42	146	130	102	194	119	19	102	35	32	64	65.1	25.4	UC212RT	52.5	36.1	T212	5.1
55	UCT211RT	64	22	38	146	130	102	171	106	19	95	35	25	64	55.6	22.2	UC211RT	43	29.4	T211	4
50	UCT210RT	49	16	37	117	102	83	149	90	16	86	29	19	49	51.6	19	UC210RT	35.5	23.2	T210	2.5
45	UCT209RT	49	16	35	117	102	83	144	87	16	83	29	19	49	49.2	19	UC209RT	33	20.5	T209	2.4
40	UCT208RT	49	16	33	114	102	83	144	88	16	83	29	19	49	49.2	19	UC208RT	29.3	17.9	T208	2.4
35	UCT207RT	37	12	30	102	89	64	129	78	13	64	22	16	37	42.9	17.5	UC207RT	25.9	15.4	T207	1.6
30	UCT206RT	37	12	28	102	89	56	113	70	10	57	22	16	37	38.1	15.9	UC206RT	19.6	11.3	T206	1.3
25	UCT205RT	32	12	24	89	76	51	97	62	10	51	19	16	32	34.1	14.3	UC205RT	14	7.9	T205	0.82
20	UCT204RD	32	12	21	89	76	51	94	61	10	51	19	16	32	31	12.7	UC204RD	12.8	6.6	T204	0.74
17	UCT203RD	32	12	21	89	76	51	94	61	10	51	19	16	32	31	12.7	UC203RD	12.8	6.6	T204	0.76
15	UCT202RD	32	12	21	89	76	51	94	61	10	51	19	16	32	31	12.7	UC202RD	12.8	6.6	T204	0.77
12	UCT201RD	32	12	21	89	76	51	94	61	10	51	19	16	32	31	12.7	UC201RD	12.8	6.6	T204	0.79

Total 13 items
