| Overall dimensions（mm) | Rated load（Paired twin type）（KN） | Rated load（Paired twin type）{kgf} | Bearing code | Legend type number | Operating point distance a0（mm） | Installation dimensions(mm) | Weight(kg) | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | 2B | 2C | γ(minimum) | γ1(3)(minimum） | Cr | Cor | Cr | Cor | Single column | DB combination | DF combination | DB | DF | da（minimum） | Db(minimum) | da（minimum） | Db(minimum) | γa(minimum) | γb(minimum） | (Reference) | |
| 380 | 519.5 | 130 | 130 | 4 | 1.5 | 565 | 1300 | 57500 | 132000 | 7976BX | DB | DF | 1 | 442.6 | 312.6 | 414 | — | 491 | 500 | 3 | 1.5 | 81.1 |
| 360 | 509.5 | 140 | 140 | 5 | 2 | 615 | 1340 | 63000 | 137000 | BT360-3 | — | DF | 4 | — | 295 | — | 385 | 477 | — | 4 | 2 | 85 |
| 340 | 540 | 180 | 180 | 5 | 2 | 780 | 1720 | 79500 | 176000 | BT340-1 | DB | — | 2 | 459.2 | — | 377 | — | — | 519 | 4 | 2 | 161 |
| 340 | 480 | 130 | 130 | 4 | 1.5 | 535 | 1150 | 54500 | 117000 | BT340-51 | DB | — | 1 | 409 | — | 373 | — | — | 461 | 3 | 1.5 | 71.6 |
| 320 | 449.5 | 112 | 112 | 3 | 1.1 | 480 | 1010 | 49000 | 103000 | BT320-51 | DB | — | 6 | 379.1 | — | 348 | — | — | 433 | 2.5 | 1 | 54.4 |
| 320 | 449.5 | 112 | 112 | 3 | 3 | 540 | 1130 | 55000 | 115000 | BA320-1 | DB | — | 1 | 278.3 | — | 348 | — | — | 426 | 2.5 | 2.5 | 55.4 |
| 310 | 429.5 | 120 | 120 | 4 | 1.5 | 460 | 940 | 47000 | 95500 | BT310-51 | DB | — | 1 | 370.5 | — | 342 | — | — | 412 | 3 | 1.5 | 52.2 |
| 310 | 429.5 | 120 | 120 | 4 | 1.5 | 520 | 1040 | 53000 | 107000 | BA310-2 | DB | — | 1 | 273.6 | — | 342 | — | — | 412 | 3 | 1.5 | 52.5 |
| 300 | 419.5 | 112 | 112 | 3 | 1.1 | 455 | 900 | 46000 | 92000 | 7960BAX | DB | DF | 4 | 358.1 | 246.1 | 327 | 320 | 397 | 404 | 2.5 | 1 | 46.7 |
| 300 | 419.5 | 112 | 112 | 3 | 1.1 | 510 | 1000 | 52000 | 102000 | 7960AX | DB | DF | 1 | 263.8 | 151.8 | 327 | — | 397 | 404 | 2.5 | 1 | 48.6 |
| 290 | 419.5 | 120 | 120 | 5 | 2 | 475 | 935 | 48500 | 95500 | BT290-52 | DB | — | 2 | 357.9 | — | 325 | — | — | 401 | 4 | 2 | 54 |
| 290 | 409.5 | 112 | 112 | 3 | 1.1 | 430 | 830 | 44000 | 84500 | BT290-2 | DB | — | 1 | 349.7 | — | 317 | — | — | 394 | 2.5 | 1 | 45.3 |
| 290 | 409.5 | 112 | 112 | 3 | 1.1 | 485 | 920 | 49500 | 94000 | BA290-2 | DB | — | 1 | 258.1 | — | 317 | — | — | 394 | 2.5 | 1 | 44.2 |
| 285 | 380 | 92 | 92 | 3 | 2 | 297 | 570 | 30500 | 58000 | BT285-1 | DB | — | 4 | 325 | — | 311 | — | — | 362 | 2.5 | 2 | 28.5 |
| 280 | 400 | 104 | 104 | 4 | 1.5 | 425 | 820 | 43500 | 84000 | BT280-2 | DB | — | 2 | 337.3 | — | 310 | — | — | 383 | 3 | 1.5 | 41.5 |
| 280 | 389.5 | 92 | 92 | 2.1 | 1.1 | 380 | 740 | 38500 | 75500 | BT280-51 | DB | — | 1 | 327.1 | — | 304 | — | — | 374 | 2 | 1 | 34.4 |
| 277 | 420 | 130 | 130 | 4 | 1.5 | 530 | 1040 | 54000 | 106000 | BT277-1 | DB | — | 1 | 358.7 | — | 307 | — | — | 402 | 3 | 1.5 | 63.1 |
| 270 | 379.5 | 92 | 92 | 2.1 | 1.1 | 400 | 750 | 41000 | 76500 | BT270-1 | DB | — | 6 | 318.7 | — | 294 | — | — | 365 | 2 | 1 | 31.7 |
| 260 | 399.5 | 130 | 130 | 4 | 1.5 | 505 | 945 | 51500 | 96500 | 7052BX | DB | DF | 1 | 341.9 | 211.9 | 290 | — | 373 | 382 | 3 | 1.5 | 57.6 |
| 260 | 379.5 | 112 | 112 | 4 | 2 | 430 | 785 | 44000 | 80000 | BT260-52 | DB | — | 2 | 324.5 | — | 290 | — | — | 362 | 3 | 2 | 41.5 |
