| Overall dimensions（mm) | Rated load(KN) | Rated load{kgf} | Bearing code | Installation dimensions(mm) | Location of action point(mm) | constant | Axial load Coefficient | Weight(kg) | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | T | B | C | Inner circleγ (minimum) | Outer ringγ (minimum) | Cr | Cor | Cr | Cor | Inner circle | Outer ring | da | db | da | db | Inner circleγa（maximum） | Outer ringγa（maximum） | A | e | Y1 | Y0 | (Reference) |
| 1270 | 1435.1 | 69.85 | 65.088 | 47.625 | 6.4 | 6.4 | 1630 | 5550 | 167000 | 565000 | LL889049 | LL889010 | 1315 | 1294 | 1392 | 1413 | 6.4 | 6.4 | 285.4 | 0.57 | 1.1 | 0.58 | 144 |
| 1155.7 | 1435.1 | 120.65 | 120.65 | 95.25 | 6.4 | 6.4 | 4150 | 12000 | 420000 | 1220000 | EE277455 | 277565 | 1227 | 1199 | 1377 | 1403 | 6.4 | 6.4 | 207.3 | 0.36 | 1.7 | 0.92 | 431 |
| 1092.2 | 1320.8 | 95.25 | 88.9 | 69.85 | 6.4 | 6.4 | 2730 | 7650 | 278000 | 780000 | EE776430 | 776520 | 1153 | 1128 | 1269 | 1301 | 6.4 | 6.4 | 270.7 | 0.57 | 1.1 | 0.58 | 249 |
| 1066.8 | 1219.2 | 65.088 | 65.088 | 42.862 | 3.3 | 3.3 | 1520 | 4750 | 155000 | 485000 | LL788349 | LL788310 | 1106 | 1090 | 1187 | 1202 | 3.3 | 3.3 | 209 | 0.47 | 1.3 | 0.7 | 108 |
| 977.9 | 1130.3 | 66.675 | 63.5 | 47.625 | 6.4 | 6.4 | 1460 | 4350 | 149000 | 445000 | LL687949 | LL687910 | 1019 | 1002 | 1095 | 1112 | 6.4 | 6.4 | 182.9 | 0.43 | 1.4 | 0.76 | 101 |
| 838.2 | 1041.4 | 93.662 | 88.9 | 66.675 | 6.4 | 6.4 | 2380 | 6350 | 243000 | 650000 | EE763330 | 763410 | 892 | 866 | 995 | 1081 | 6.4 | 6.4 | 178.1 | 0.44 | 1.4 | 0.75 | 171 |
| 774.7 | 965.2 | 93.662 | 80.962 | 66.675 | 6.4 | 3.3 | 2100 | 5200 | 214000 | 530000 | EE752305 | 752380 | 822 | 800 | 926 | 943 | 6.4 | 3.3 | 158.8 | 0.4 | 1.5 | 0.83 | 137 |
| 762 | 965.2 | 93.662 | 80.962 | 66.675 | 6.4 | 3.3 | 2100 | 5200 | 214000 | 530000 | EE752300 | 752380 | 815 | 793 | 926 | 943 | 6.4 | 3.3 | 158.8 | 0.4 | 1.5 | 0.83 | 147 |
| 762 | 889 | 69.85 | 69.85 | 50.8 | 3.3 | 3.3 | 1160 | 3450 | 119000 | 350000 | LL483449 | LL483418 | 797 | 780 | 861 | 876 | 3.3 | 3.3 | 133.8 | 0.38 | 1.6 | 0.87 | 68.1 |
| 762 | 889 | 63.5 | 63.5 | 50.8 | 3.3 | 3.3 | 1160 | 3450 | 119000 | 350000 | EE175301 | 175350 | 797 | 780 | 861 | 876 | 3.3 | 3.3 | 131.4 | 0.38 | 1.6 | 0.87 | 64.4 |
| 749.3 | 990.6 | 159.5 | 160.338 | 123 | 6.4 | 6.4 | 4400 | 11700 | 450000 | 1200000 | LM283649 | LM283610 | 815 | 782 | 938 | 969 | 6.4 | 6.4 | 165.2 | 0.33 | 1.8 | 0.99 | 329 |
| 723.9 | 914.4 | 84.138 | 80.962 | 60.325 | 3.3 | 6.4 | 1870 | 4800 | 191000 | 490000 | EE755285 | 755360 | 770 | 752 | 870 | 891 | 3.3 | 6.4 | 140.5 | 0.38 | 1.6 | 0.87 | 126 |
| 711.2 | 914.4 | 85.725 | 82.55 | 60.325 | 6.4 | 6.4 | 1870 | 4800 | 191000 | 490000 | EE755280 | 755360 | 767 | 746 | 870 | 891 | 6.4 | 6.4 | 140.5 | 0.38 | 1.6 | 0.87 | 136 |
| 685.8 | 876.3 | 93.662 | 92.075 | 69.85 | 6.4 | 6.4 | 2160 | 5550 | 220000 | 565000 | EE655270 | 655345 | 737 | 712 | 832 | 857 | 6.4 | 6.4 | 149.9 | 0.42 | 1.4 | 0.79 | 134 |
| 673.1 | 793.75 | 66.675 | 61.912 | 49.212 | 6.4 | 6.4 | 995 | 2660 | 102000 | 271000 | LL481448 | LL481411 | 708 | 691 | 764 | 781 | 6.4 | 6.4 | 119.7 | 0.36 | 1.7 | 0.92 | 52 |
| 660.4 | 854.075 | 87.725 | 85.468 | 60.325 | 6.4 | 6.4 | 2000 | 4650 | 204000 | 490000 | EE749260 | 749336 | 712 | 690 | 813 | 831 | 9.7 | 6.4 | 124.5 | 0.35 | 1.7 | 0.94 | 119 |
| 660.4 | 812.8 | 95.25 | 95.25 | 73.025 | 6.4 | 6.4 | 2200 | 5900 | 224000 | 600000 | L281148 | L281110 | 701 | 678 | 778 | 799 | 6.4 | 6.4 | 123.1 | 0.33 | 1.8 | 0.99 | 105 |
| 635 | 736.6 | 57.15 | 53.975 | 41.275 | 3.3 | 3.3 | 870 | 2500 | 89000 | 255000 | 80780 | 80720 | 664 | 648 | 712 | 726 | 3.3 | 3.3 | 125 | 0.44 | 1.4 | 0.75 | 36.6 |
| 609.6 | 787.4 | 93.662 | 93.662 | 69.85 | 6.4 | 6.4 | 2000 | 4800 | 204000 | 490000 | EE649240 | 649310 | 659 | 632 | 749 | 771 | 6.4 | 6.4 | 129.2 | 0.37 | 1.6 | 0.89 | 110 |
| 609.6 | 774.7 | 87.725 | 79.375 | 60.32 | 6.4 | 6.4 | 1780 | 4700 | 181000 | 480000 | L580049 | L580010 | 654 | 634 | 737 | 755 | 6.4 | 6.4 | 130.5 | 0.4 | 1.5 | 0.82 | 90.1 |
