| Overall dimensions（mm) | Rated load(KN) | Rated load{kgf} | Bearing code | Installation dimensions(mm) | constant | Axial load Coefficient | Weight(kg) | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | C2 | γ1 （minimum） | γ (minimum) | Cr | Cor | Cr | Cor | db | da | γa (maximum) | γb (maximum) | e | Y2 | Y3 | Y0 | (Reference) | |
| 540 | 860 | 256 | 256 | 7.5 | 7.5 | 5400 | 12100 | 5550000 | 240000 | 540KDH8601+K | 591 | 786 | 6 | 6 | 0.7 | 1.4 | 0.97 | 0.94 | 575 |
| 500 | 720 | 185 | 218 | 6 | 6 | 2950 | 6800 | 300000 | 695000 | 500KDH7201+K | 532 | 664 | 5 | 5 | 0.7 | 1.4 | 0.97 | 0.95 | 262 |
| 460 | 618 | 150 | 150 | 5 | 4 | 1600 | 4150 | 163000 | 420000 | 460KDH6101A+K | 484 | 575 | 3 | 4 | 1.1 | 0.96 | 0.64 | 0.63 | 117 |
| 400 | 650 | 200 | 200 | 6 | 6 | 2870 | 6300 | 293000 | 640000 | 400KDH6503+K | 439 | 586 | 5 | 5 | 1.1 | 0.96 | 0.64 | 0.63 | 264 |
| 360 | 550 | 148 | 148 | 6 | 5 | 1940 | 3900 | 198000 | 400000 | 360KDH5501+K | 389 | 506 | 4 | 5 | 0.7 | 1.4 | 0.97 | 0.94 | 123 |
| 350 | 618 | 200 | 200 | 6 | 6 | 2880 | 5450 | 293000 | 555000 | 350KDH6102 | 395 | 556 | 5 | 5 | 0.87 | 1.2 | 0.78 | 0.76 | 236 |
| 330 | 650 | 248 | 248 | 6 | 7.5 | 3350 | 6100 | 340000 | 620000 | 330KDH6501+K | 379 | 572 | 6 | 5 | 1.3 | 0.8 | 0.54 | 0.52 | 369 |
| 320 | 620 | 264 | 296 | 6 | 5 | 3900 | 7550 | 395000 | 770000 | 320KDH6201+K | 361 | 542 | 4 | 5 | 0.94 | 1.1 | 0.72 | 0.7 | 399 |
| 305.079 | 500 | 200 | 200 | 6.4 | 4.8 | 2500 | 6050 | 255000 | 615000 | 305KDH5001A+K | 335 | 447 | 4.8 | 6.4 | 0.7 | 1.4 | 0.97 | 0.94 | 162 |
| 304.8 | 499.948 | 158.75 | 203.2 | 3.3 | 6.4 | 2040 | 4050 | 208000 | 415000 | * 304KDH4951+K | 327 | 444 | 6.4 | 3.3 | 1.2 | 0.85 | 0.57 | 0.56 | 145 |
| 300 | 520 | 180 | 210 | 4 | 4 | 2310 | 4500 | 236000 | 460000 | 300KDH5201A+K | 326 | 461 | 3 | 3 | 1.2 | 0.85 | 0.57 | 0.56 | 178 |
| 300 | 500 | 200 | 200 | 5 | 5 | 2500 | 6050 | 255000 | 615000 | 300KDH5001+K | 332 | 447 | 4 | 4 | 0.7 | 1.4 | 0.97 | 0.94 | 167 |
| 290 | 450 | 180 | 180 | 2.5 | 4 | 1970 | 4250 | 201000 | 435000 | 290KDH4501+K | 308 | 408 | 3 | 2 | 0.64 | 1.6 | 1.1 | 1 | 103 |
| 279.578 | 381 | 88.9 | 111.125 | 3.3 | 6.4 | 825 | 1800 | 84000 | 184000 | * 89111D/ 89150+K | 296 | 354 | 6.4 | 3.3 | 0.58 | 1.7 | 1.2 | 1.1 | 32.6 |
| 279.4 | 482.6 | 177.8 | 177.8 | 6 | 4.8 | 2380 | 4650 | 243000 | 475000 | * 279KDH4851+K | 310 | 433 | 4.8 | 6 | 0.7 | 1.4 | 0.97 | 0.94 | 139 |
| 260.35 | 419.1 | 155.575 | 158.75 | 3.3 | 3.3 | 1640 | 3650 | 168000 | 370000 | * EE435103D / 435165+K | 282 | 378 | 3.3 | 3.3 | 0.61 | 1.7 | 1.1 | 1.1 | 85.2 |
| 260 | 458.5 | 155 | 155 | 5 | 5 | 1760 | 3300 | 179000 | 340000 | 260KDH4501A+K | 293 | 411 | 4 | 4 | 0.87 | 1.2 | 0.78 | 0.76 | 110 |
| 260 | 389.5 | 105 | 105 | 1.5 | 3 | 945 | 1880 | 96000 | 192000 | 260KDH3801+K | 277 | 358 | 2.5 | 1.5 | 0.87 | 1.2 | 0.78 | 0.76 | 42.7 |
| 228.6 | 431.8 | 177.8 | 177.8 | 5 | 5 | 1980 | 3600 | 202000 | 365000 | * 228KDH4351+K | 257 | 382 | 5 | 5 | 0.93 | 1.1 | 0.73 | 0.71 | 117 |
| 228.6 | 431.8 | 158.75 | 158.75 | 6.4 | 6.4 | 1520 | 2640 | 155000 | 269000 | * EE113090D / 113170+K | 259 | 378 | 6.4 | 6.4 | 0.88 | 1.1 | 0.77 | 0.75 | 99.5 |
