| Overall dimensions（mm) | Rated static load(KN） | Rated static load{kgf} | Bearing code | Size（mm) | Weight(kg) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| D | d1 | F(minimum) | T | t1 | C0a | C0a | R | T | γ(minimum) | U | V | ThA | ThB | (Reference) | |
| 900 | 930 | 750 | 275 | 231 | 93000 | 9500000 | 930TFX01 | 1800 | 60 | 4 | — | — | M36 | M48 | 1270 |
| 847.6 | 841 | 650 | 250 | 212 | 79000 | 8050000 | 847TFX01 | 1652 | 43 | 5 | — | — | M42 | M42 | 966 |
| 800 | 800 | 700 | 250 | 206 | 71500 | 7300000 | 800TFX01 | 1524 | 43 | 7 | — | — | M36 | M48 | 857 |
| 710 | 710 | 480 | 260 | 235 | 54500 | 5600000 | 710TFX01 | 1400 | 40 | 4 | — | — | M24 | M24 | 706 |
| 692.15 | 689.75 | 495.3 | 311.45 | 280 | 59500 | 6050000 | 692TFX01 | 1803.4 | 38.1 | 3 | 13.5 | 3.2 | M24 | M42 | 805 |
| 641.35 | 638.99 | 558.8 | 212.67 | 184.15 | 51500 | 5250000 | 641TFX01 | 1524 | 38.1 | 3.3 | 13.5 | 3.2 | M24 | M42 | 472 |
| 609.6 | 607.24 | 533.4 | 204.01 | 170.01 | 47000 | 4800000 | 609TFX03 | 1524 | 38.1 | 3.3 | 13.5 | 3.2 | M24 | M42 | 409 |
| 609.6 | 607.24 | 533.4 | 204.01 | 177.8 | 47000 | 4800000 | 609TFX01 | 1524 | 38.1 | 3.3 | 13.5 | 3.2 | M30 | M42 | 409 |
| 581.025 | 578.66 | 508 | 196.65 | 168.28 | 41500 | 4200000 | 581TFX02 | 1308.1 | 38.1 | 3.3 | 13.5 | 3.2 | 8UNC | 7UNC | 358 |
| 581.025 | 578.66 | 508 | 193.78 | 168.28 | 41500 | 4200000 | 581TFX01 | 1422.4 | 38.1 | 3.2 | 13.5 | 3.2 | M24 | M42 | 353 |
| 555.625 | 553.26 | 482.6 | 191.15 | 165.1 | 38000 | 3900000 | 555TFX01 | 1270 | 38.1 | 3.3 | 12.7 | 3.2 | M24 | — | 318 |
| 533.4 | 531.01 | 457 | 177.8 | 161.92 | 34500 | 3500000 | 533TFX01 | 1981.2 | 31.75 | 1.6 | 9.5 | 9.5 | M24 | M36 | 273 |
| 523.875 | 521.52 | 457.2 | 176.66 | 153.29 | 34500 | 3500000 | 523TFX01 | 1270 | 34.92 | 3.3 | 13.5 | 3.2 | M24 | M36 | 261 |
| 495.3 | 492.94 | 431.8 | 170.61 | 146.05 | 31500 | 3200000 | 495TFX01 | 1066.8 | 34.92 | 3.3 | 13.5 | 3.2 | M24 | M30 | 225 |
| 482.6 | 480.21 | 381 | 145.54 | 130.18 | 27700 | 2820000 | 482TFX01 | 1905 | 38.1 | 1.6 | 13.5 | 3.2 | M24 | M36 | 184 |
| 471 | 453 | 390 | 145.54 | 124 | 24100 | 2460000 | 471TFX01 | 1100 | 38.1 | 3.5 | — | — | M24 | M36 | 174 |
| 438.15 | 435.79 | 381 | 150.67 | 130.18 | 22200 | 2260000 | 438TFX01 | 1016 | 31.75 | 3.2 | 13.5 | 3.2 | M24 | M36 | 155 |
| 409.575 | 407.21 | 355.6 | 142.23 | 122.22 | 20500 | 2090000 | 409TFX01 | 1016 | 28.57 | 3.3 | 9.5 | 2.5 | M24 | M30 | 128 |
| 404.4 | 407.21 | 355.6 | 142.23 | 122.22 | 20500 | 2090000 | 407TFX01 | 1016 | 28.57 | 3.3 | — | — | M24 | M30 | 127 |
| 377.825 | 375.46 | 330.2 | 129.01 | 111.12 | 17700 | 1810000 | 377TFX01 | 914.4 | 25.4 | 1.5 | 10.3 | 2.4 | M24 | M30 | 98.7 |
