| Overall dimensions（mm) | Rated static load(KN） | Rated static load{kgf} | Bearing code | Size（mm) | Weight(kg) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| D | d1 | F(minimum) | T | C0a | C0a | R | T | γ(minimum) | U | V | ThA | ThB | (reference) | |
| 880 | 930 | 627 | 234.95 | 93000 | 9500000 | 930TFV01 | 1524 | 50 | 4 | — | — | M42 | M42 | 1090 |
| 641.35 | 638.99 | 558.8 | 184.15 | 51500 | 5250000 | 641TFV01 | 762 | 38.1 | 3.2 | 13.5 | 3.2 | M24 | M42 | 405 |
| 615.2 | 607 | 400 | 243.92 | 47000 | 4800000 | 615TFV01 | 635 | 38.1 | 3 | 13.5 | 3.5 | M30 | — | 493 |
| 609.6 | 607.24 | 533.4 | 177.8 | 47000 | 4800000 | 609TFV01 | 762 | 38.1 | 3.3 | 13.5 | 3.2 | M30 | M42 | 353 |
| 581.025 | 578.66 | 508 | 168.28 | 41500 | 4200000 | 581TFV01 | 711.2 | 38.1 | 3.2 | 13.5 | 3.2 | M24 | M42 | 303 |
| 555.625 | 553.26 | 482.6 | 165.1 | 38000 | 3900000 | 555TFV01 | 635 | 38.1 | 3.2 | 13.5 | 3.2 | M24 | M36 | 272 |
| 554 | 555 | 465.4 | 190.5 | 38000 | 3900000 | 554TFV01A | 1270 | 50 | 3 | — | — | M24 | M42 | 312 |
| 554 | 555 | 414 | 190.5 | 38000 | 3900000 | 554TFV01 | 1270 | 50 | 3 | 9.5 | 6 | M24 | — | 312 |
| 551.6 | 539.75 | 435.5 | 158.75 | 35000 | 3550000 | 551TFV01 | 635 | 24.65 | 4 | 10.6 | 2.5 | M24 | M24 | 258 |
| 523.875 | 521.51 | 457.2 | 152.4 | 34500 | 3500000 | 523TFV01 | 635 | 34.92 | 3.2 | 13.5 | 3.2 | M24 | M36 | 223 |
| 508 | 501.65 | 341.3 | 165.1 | 31000 | 3150000 | 508TFV01 | 508 | 34.92 | 3.2 | 12.7 | 3.2 | M24 | M36 | 228 |
| 495.3 | 492.94 | 431.8 | 146.05 | 31500 | 3200000 | 495TFV01 | 558.8 | 34.92 | 3.3 | 13.5 | 3.2 | M24 | M36 | 191 |
| 438.15 | 435.79 | 381 | 130.18 | 22200 | 2260000 | 438TFV01 | 508 | 31.75 | 3.2 | 13.5 | 3.2 | M24 | M36 | 133 |
| 409.575 | 407.21 | 355.6 | 122.22 | 20500 | 2090000 | 409TFV01 | 508 | 28.58 | 3.2 | 10.3 | 2.4 | M24 | M30 | 109 |
| 377.825 | 375.46 | 330.2 | 111.12 | 17700 | 1810000 | 377TFV01 | 457.2 | 25.4 | 1.5 | 10.3 | 2.4 | M24 | M30 | 84.7 |
| 320.675 | 318.31 | 279.4 | 95.25 | 12600 | 1280000 | 320TFV01 | 381 | 22.22 | 1.5 | 10.3 | 2.4 | M24 | — | 52.3 |
| 266.7 | 264.34 | 228.6 | 86.37 | 8350 | 855000 | 266TFV02 | 250 | 19.05 | 1.6 | 7.9 | 2 | M20 | — | 35.5 |
| 266.7 | 264.34 | 228.6 | 80.95 | 8400 | 855000 | 266TFV01 | 304.8 | 19.05 | 1.6 | 7.9 | 2 | M20 | — | 30.8 |
| 203.2 | 200.8 | 177.8 | 65.07 | 4850 | 495000 | 203TFV01 | 254 | 15.88 | 1.6 | 6.3 | 1.2 | — | — | 14.3 |
| 149.225 | 146.86 | 127 | 47.62 | 2520 | 257000 | 149TFV01 | 228.6 | 12.7 | 1.6 | 4.8 | 1.2 | M12X | — | 5.6 |
