| shaft diameter (mm) |
Bearing unit type number | Main dimensions（mm） | Installation bolt specification | Basic Rated Load(kN) | Bearing Seat Type Number | Type number with stainless steel cover With rubber sealing cover （Shaft end shield） |
Weight（kg） | |||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| H | L | A2 | A1 | A | N | L | Ao | B | S | A4 | A6 | Type number | Cr | Cor | standard | Compatible with stainless steel cover | lidless | with lid | ||||
| 40 | MUCAFし208V-J | 175 | 144 | 21 | 16 | 36 | 16 | 0 | 51.2 | 49.2 | 19 | 62 | 10 | M14 | MUC 208V | 24.9 | 14.3 | AFし208J | AFし208C-J | MUCAFし208VC(E)-J | 0.95 | 0.98 |
| 35 | MICAFし207V-J | 161 | 130 | 19 | 16 | 34 | 16 | 90 | 44.4 | 42.9 | 17.5 | 54 | 8 | M14 | MUC 207V | 22 | 12.3 | AFし207J | AFし207C-J | MUCAFし207VC(E)-J | 0.74 | 0.78 |
| 30 | MUCAFし206V-J | 148 | 117 | 18 | 14 | 31 | 16 | 80 | 40.2 | 38.1 | 15.9 | 51 | 9 | M14 | MUC 206V | 16.7 | 9 | AFし206J | AFし206C-J | MUCAFし206VC(E)-J | 0.53 | 0.57 |
| 25 | MUCAFし205V-J | 130 | 99 | 16 | 14 | 27 | 16 | 68 | 35.8 | 34.1 | 14.3 | 47 | 9 | M14 | MUC 205V | 11.9 | 6.3 | AFし205J | AFし205C-J | MUCAFし205VC(E)-J | 0.34 | 0.38 |
| 20 | MUCAFし204V-J | 113 | 90 | 15 | 12 | 25.5 | 12 | 60 | 33.3 | 31 | 12.7 | 43 | 8 | M10 | MUC 204V | 10.9 | 5.3 | AFし204J | AFし204C-J | MUCAFし204VC(E)-J | 0.26 | 0.29 |
| 17 | MUCAFし203V-J | 113 | 90 | 15 | 12 | 25.5 | 12 | 60 | 33.3 | 31 | 12.7 | 43 | 8 | M10 | MUC 203V | 10.9 | 5.3 | AFし204J | AFし204C-J | MUCAFし203VC(E)-J | 0.28 | 0.31 |
| 15 | MUCAFし202V-J | 113 | 90 | 15 | 12 | 25.5 | 12 | 60 | 33.3 | 31 | 12.7 | 43 | 8 | M10 | MUC 202V | 10.9 | 5.3 | AFし204J | AFし204C-J | MUCAFし202VC(E)-J | 0.29 | 0.32 |
| 12 | MUCAFし201V-J | 113 | 90 | 15 | 12 | 25.5 | 12 | 60 | 33.3 | 31 | 12.7 | 43 | 8 | M10 | MUC 201V | 10.9 | 5.3 | AFし204J | AFし204C-J | MUCAFし201VC(E)-J | 0.31 | 0.34 |
