| Overall dimensions（mm) | Rated load(N) | Rated speed min-1 | Bearing code | Installation dimensions(mm) | Weight(kg) | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | T | C | γ(minimum) | γ1(minimum) | Ca | C0a | Grease lubrication | Oil lubrication | da | da | γa（maximum） | γb(maximum） | (Reference) | |
| 400 | 540 | 164 | 82 | 4 | 1.5 | 495000 | 2700000 | 600 | 850 | 400 TAC 29D+L | 454 | 513 | 3 | 1.5 | 91.5 |
| 380 | 520 | 164 | 82 | 4 | 1.5 | 485000 | 2560000 | 630 | 900 | 380 TAC 29D+L | 434 | 493 | 3 | 1.5 | 87.5 |
| 360 | 480 | 144 | 72 | 3 | 1.1 | 420000 | 2130000 | 710 | 950 | 360 TAC 29D+L | 408 | 459 | 2.5 | 1 | 61.5 |
| 340 | 460 | 144 | 72 | 3 | 1.1 | 415000 | 2020000 | 750 | 1000 | 340 TAC 29D+L | 388 | 439 | 2.5 | 1 | 58.5 |
| 320 | 440 | 144 | 72 | 3 | 1.1 | 405000 | 1920000 | 800 | 1100 | 320 TAC 29D+L | 368 | 419 | 2.5 | 1 | 55.5 |
| 300 | 420 | 144 | 72 | 3 | 1.1 | 395000 | 1810000 | 850 | 1200 | 300 TAC 29D+L | 348 | 399 | 2.5 | 1 | 49.8 |
| 280 | 420 | 164 | 82 | 4 | 1.5 | 440000 | 1960000 | 850 | 1200 | 280 TAC 20D+L | 334 | 393 | 3 | 1 | 68 |
| 280 | 380 | 120 | 60 | 2.1 | 1.1 | 320000 | 1470000 | 1400 | 1600 | 280 TAC 29D+L | 304 | 360 | 2 | 1 | 33.5 |
| 260 | 400 | 164 | 82 | 4 | 1.5 | 440000 | 1890000 | 900 | 1300 | 260 TAC 20D+L | 316 | 375 | 3 | 1.5 | 64.5 |
| 260 | 360 | 120 | 60 | 2.1 | 1.1 | 315000 | 1390000 | 1500 | 1700 | 260 TAC 29D+L | 283 | 341 | 2 | 1 | 31.5 |
| 240 | 360 | 144 | 72 | 3 | 1.1 | 360000 | 1450000 | 1000 | 1400 | 240 TAC 20D+L | 290 | 341 | 2.5 | 1 | 44 |
| 240 | 320 | 96 | 48 | 2.1 | 1.1 | 213000 | 980000 | 1700 | 1800 | 240 TAC 29D+L | 263 | 301 | 2 | 1 | 18.3 |
| 220 | 340 | 144 | 72 | 3 | 1.1 | 360000 | 1390000 | 1100 | 1500 | 220 TAC 20D+L | 270 | 320 | 2.5 | 1 | 41 |
| 220 | 300 | 96 | 48 | 2.1 | 1.1 | 210000 | 930000 | 1800 | 2000 | 220 TAC 29D+L | 242 | 282 | 2 | 1 | 17 |
| 200 | 310 | 132 | 66 | 2,1 | 1.1 | 315000 | 1180000 | 1800 | 2000 | 200 TAC 20D+L | 212 | 298 | 2 | 1 | 31.5 |
| 200 | 280 | 96 | 48 | 2.1 | 1.1 | 204000 | 855000 | 1900 | 2100 | 200 TAC 29D+L | 212 | 268 | 2 | 1 | 15.7 |
| 190 | 290 | 120 | 60 | 2.1 | 1.1 | 285000 | 1060000 | 1900 | 2100 | 190 TAC 20D+L | 202 | 278 | 2 | 1 | 24.4 |
| 190 | 260 | 84 | 42 | 2 | 1 | 161000 | 695000 | 2000 | 2300 | 190 TAC 29D+L | 200 | 250 | 2 | 1 | 11.2 |
| 180 | 280 | 120 | 60 | 2.1 | 1.1 | 281000 | 1020000 | 2000 | 2200 | 180 TAC 20D+L | 192 | 268 | 2 | 1 | 23.4 |
| 180 | 250 | 84 | 42 | 2 | 1 | 158000 | 655000 | 2100 | 2400 | 180 TAC 29D+L | 190 | 240 | 2 | 1 | 10.7 |
