| Overall dimensions（mm) | Rated load(KN) | Rated load{kgf} | Bearing code | Installation dimensions(mm) | constant | Axial load Coefficient | Weight(kg) | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | γ(minimum) | Cr | Cor | Cr | Cor | Cylindrical hole | Conical hole | da（minimum） | da(maximum） | da(maximum） | da（minimum） | γa（maximum） | e | Y2 | Y3 | Y0 | (Reference) |
| 500 | 670 | 128 | 5 | 2460 | 5550 | 250000 | 565000 | TL239/500CAE4 | TL239/500CAKE4 | 522 | — | 648 | 622 | 4 | 0.17 | 6 | 4 | 3.9 | 124 |
| 460 | 620 | 118 | 4 | 2220 | 4950 | 227000 | 505000 | TL23992CAE4 | TL23992CAKE4 | 478 | — | 602 | 573 | 3 | 0.17 | 5.9 | 4 | 3.9 | 100 |
| 440 | 650 | 157 | 6 | 3150 | 6350 | 320000 | 645000 | TL23088CAE4 | TL23088CAKE4 | 468 | — | 622 | 587 | 5 | 0.23 | 4.3 | 2.9 | 2.8 | 173 |
| 420 | 560 | 106 | 4 | 1870 | 4250 | 191000 | 430000 | TL23984CAE4 | TL23984CAKE4 | 438 | — | 542 | 521 | 3 | 0.17 | 6 | 4 | 3.9 | 71.6 |
| 400 | 600 | 148 | 5 | 2970 | 5900 | 305000 | 605000 | TL23080CAE4 | TL23080CAKE4 | 422 | — | 578 | 540 | 4 | 0.23 | 4.4 | 3 | 2.9 | 146 |
| 380 | 520 | 106 | 4 | 1870 | 4100 | 190000 | 420000 | TL23976CAE4 | TL23976CAKE4 | 398 | — | 502 | 482 | 3 | 0.18 | 5.5 | 3.7 | 3.6 | 65.4 |
| 360 | 540 | 134 | 4 | 2390 | 4700 | 244000 | 480000 | TL23072CAE4 | TL23072CAKE4 | 382 | — | 518 | 485 | 4 | 0.24 | 4.2 | 2.8 | 2.8 | 106 |
| 340 | 580 | 190 | 5 | 3600 | 6600 | 370000 | 670000 | TL23168CAE4 | TL23168CAKE4 | 362 | — | 558 | 499 | 4 | 0.31 | 3.2 | 2.1 | 2.1 | 206 |
| 340 | 520 | 133 | 5 | 2280 | 4400 | 232000 | 445000 | TL23068CAE4 | TL23068CAKE4 | 362 | — | 458 | 465 | 4 | 0.24 | 4.2 | 2.8 | 2.8 | 101 |
| 320 | 540 | 176 | 5 | 3050 | 5500 | 315000 | 560000 | TL23164CAE4 | TL23164CAKE4 | 342 | — | 518 | 466 | 4 | 0.31 | 3.2 | 2.1 | 2.1 | 162 |
| 300 | 540 | 192 | 5 | 3400 | 5900 | 350000 | 600000 | TL23260CAE4 | TL23260CAKE4 | 322 | — | 518 | 458 | 4 | 0.35 | 2.9 | 1.9 | 1.9 | 189 |
| 300 | 500 | 160 | 5 | 2670 | 4800 | 273000 | 490000 | TL23160CAE4 | TL23160CAKE4 | 322 | — | 478 | 433 | 4 | 0.31 | 3.3 | 2.2 | 2.2 | 125 |
| 300 | 460 | 118 | 4 | 1920 | 3700 | 196000 | 375000 | TL23060CAE4 | TL23060CAKE4 | 318 | — | 442 | 413 | 3 | 0.24 | 4.2 | 2.8 | 2.7 | 70.5 |
| 300 | 420 | 90 | 3 | 1230 | 2490 | 125000 | 254000 | TL23960CAE4 | TL23960CAKE4 | 314 | — | 406 | 386 | 2.5 | 0.19 | 5.2 | 3.5 | 3.4 | 38.2 |
| 280 | 500 | 176 | 5 | 2880 | 4900 | 294000 | 500000 | TL23256CAE4 | TL23256CAKE4 | 302 | — | 478 | 425 | 4 | 0.35 | 2.9 | 1.9 | 1.9 | 147 |
| 280 | 460 | 146 | 5 | 2230 | 4000 | 228000 | 410000 | TL23156CAE4 | TL23156CAKE4 | 302 | — | 438 | 400 | 4 | 0.3 | 3.3 | 2.2 | 2.2 | 94.3 |
| 280 | 420 | 106 | 4 | 1540 | 2950 | 157000 | 300000 | TL23056CAE4 | TL23056CAKE4 | 298 | — | 402 | 377 | 3 | 0.24 | 4.2 | 2.8 | 2.7 | 50.5 |
| 280 | 380 | 75 | 2.1 | 925 | 1950 | 94500 | 199000 | TL23956CAE4 | TL23956CAKE4 | 292 | — | 368 | 351 | 2 | 0.18 | 5.7 | 3.9 | 3.8 | 24.5 |
| 260 | 440 | 144 | 4 | 2160 | 3750 | 221000 | 385000 | TL23152CAE4 | TL23152CAKE4 | 278 | — | 422 | 380 | 3 | 0.32 | 3.2 | 2.1 | 2.1 | 88.2 |
| 250 | 400 | 104 | 4 | 1430 | 2580 | 145000 | 263000 | TL23052CAE4 | TL23052CAKE4 | 278 | — | 382 | 356 | 3 | 0.25 | 4.1 | 2.7 | 2.7 | 46.6 |
