| Overall dimensions（mm) | Rated load(KN) | Rated load{kgf} | Rated speed min-1 | Bearing code | Installation dimensions(mm) | Point of action Position(mm) | constant | Axial load Coefficient | Weight(kg) | ||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | T | B | C | Inner circle γ(minimum) | Outer ring γ1(minimum) | Cr | Cor | Cr | Cor | Grease lubrication | Oil lubrication | Inner circle | Outer ring | da | db | da | db | Inner circle γa(maximum） | Outer ring γa（maximum） | A | e | Y1 | Y0 | (Reference) |
| 203.2 | 482.6 | 117.475 | 95.25 | 73.025 | 6.4 | 6.4 | 1190 | 1590 | 121000 | 163000 | — | — | EE380080 | 380190 | 274 | 236 | 408 | 451 | 6.4 | 6.4 | 148.6 | 0.87 | 0.69 | 0.38 | 88.7 |
| 203.2 | 406.4 | 92.075 | 88.897 | 57.15 | 6.4 | 6.4 | 935 | 1310 | 95000 | 133000 | — | — | EE114080 | 114160 | 260 | 226 | 352 | 387 | 6.4 | 6.4 | 11.9 | 0.79 | 0.75 | 0.42 | 48.1 |
| 203.2 | 368.3 | 92.075 | 88.897 | 63.5 | 3.3 | 3.3 | 875 | 1340 | 89000 | 137000 | — | — | EE420801 | 421450 | 246 | 227 | 333 | 353 | 3.3 | 3.3 | 78.9 | 0.42 | 1.4 | 0.79 | 36.9 |
| 203.2 | 365.049 | 92.075 | 88.897 | 63.5 | 3.3 | 3.3 | 875 | 1340 | 89000 | 137000 | — | — | EE420801 | 421437 | 246 | 227 | 332 | 351 | 3.3 | 3.3 | 78.9 | 0.42 | 1.4 | 0.79 | 36 |
| 203.2 | 360 | 92.075 | 88.897 | 63.5 | 3.3 | 3.3 | 875 | 1340 | 89000 | 137000 | — | — | EE420801 | 421417 | 246 | 227 | 329 | 349 | 3.3 | 3.3 | 78.9 | 0.42 | 1.4 | 0.79 | 34.5 |
| 203.2 | 317.5 | 66.675 | 66.675 | 50.8 | 7.9 | 3.3 | 575 | 1060 | 59000 | 108000 | — | — | 93800A | 93126 | 240 | 217 | 286 | 306 | 7.9 | 3.3 | 75.8 | 0.52 | 1.1 | 0.63 | 18.6 |
| 203.2 | 317.5 | 66.675 | 66.675 | 50.8 | 4.3 | 3.3 | 575 | 1060 | 59000 | 108000 | — | — | 93800 | 93126 | 237 | 217 | 286 | 306 | 4.3 | 3.3 | 75.8 | 0.52 | 1.1 | 0.63 | 18.7 |
| 203.2 | 317.5 | 66.675 | 66.675 | 50.8 | 4.3 | 3.3 | 615 | 995 | 62500 | 102000 | — | — | EE122080 | 122125 | 234 | 218 | 293 | 305 | 4.3 | 3.3 | 55.9 | 0.3 | 2 | 1.1 | 17.4 |
| 203.2 | 317.5 | 63.5 | 63.5 | 46.038 | 7.9 | 3.3 | 575 | 1060 | 59000 | 108000 | — | — | 93800A | 93125 | 240 | 217 | 288 | 306 | 7.9 | 3.3 | 71 | 0.52 | 1.1 | 0.63 | 17.7 |
| 203.2 | 317.5 | 63.5 | 63.5 | 46.038 | 4.3 | 3.3 | 575 | 1060 | 59000 | 108000 | — | — | 93800 | 93125 | 237 | 217 | 288 | 306 | 4.3 | 3.3 | 71 | 0.52 | 1.1 | 0.63 | 17.8 |
| 203.2 | 317.5 | 53.975 | 53.975 | 34.925 | 4 | 3.3 | 460 | 725 | 47000 | 74000 | — | — | EE132083 | 132125 | 232 | 219 | 293 | 302 | 4 | 3.3 | 48 | 0.31 | 1.9 | 1.1 | 13.5 |
| 203.2 | 282.575 | 46.038 | 46.038 | 36.512 | 3.5 | 3.3 | 365 | 800 | 37500 | 81500 | 1000 | 1400 | 67983 | 67920 | 222 | 216 | 260 | 275 | 3.5 | 3.3 | 61.9 | 0.51 | 1.2 | 0.65 | 8.85 |
| 203.2 | 276.225 | 42.862 | 42.862 | 34.133 | 3.3 | 3.3 | 335 | 620 | 34500 | 63500 | — | — | LM241149 | LM241110 | 224 | 213 | 259 | 269 | 3.3 | 3.3 | 44 | 0.32 | 1.9 | 1 | 6.84 |
| 203.2 | 261.142 | 285.575 | 27.783 | 214.433 | 1.5 | 1.5 | 176 | 355 | 18000 | 36500 | — | — | LL641149 | LL641110 | 219 | 212 | 247 | 254 | 1.5 | 1.5 | 43.7 | 0.41 | 1.5 | 0.81 | 3.54 |
| 201.612 | 360 | 92.075 | 88.897 | 63.5 | 3.3 | 3.3 | 875 | 1340 | 89000 | 137000 | — | — | EE420793 | 421417 | 246 | 226 | 329 | 349 | 3.3 | 3.3 | 78.9 | 0.42 | 1.4 | 0.79 | 34.9 |
| 200.025 | 393.7 | 111.125 | 111.125 | 84.138 | 6.4 | 6.4 | 1300 | 2030 | 133000 | 207000 | — | — | HH144642 | HH144614 | 251 | 227 | 352 | 374 | 6.4 | 6.4 | 78.1 | 0.3 | 2 | 1.1 | 57.4 |
| 200.025 | 384.175 | 112.712 | 112.712 | 90.488 | 6.4 | 6.4 | 1220 | 2220 | 124000 | 227000 | — | — | H247535 | H247510 | 258 | 234 | 344 | 369 | 6.4 | 6.4 | 84.2 | 0.33 | 1.8 | 0.99 | 58.8 |
| 200.025 | 355.6 | 69.85 | 69.85 | 49.212 | 6.8 | 1.5 | 690 | 1190 | 70000 | 121000 | — | — | EE130787 | 131400 | 250 | 232 | 329 | 340 | 6.8 | 1.5 | 59.8 | 0.33 | 1.8 | 0.99 | 28.3 |
| 200.025 | 333.375 | 69.85 | 69.85 | 52.388 | 6.4 | 6.4 | 690 | 1190 | 70000 | 121000 | — | — | HM743337 | HM743310 | 242 | 222 | 302 | 322 | 6.4 | 6.4 | 71.3 | 0.44 | 1.4 | 0.75 | 23.3 |
| 200.025 | 317.5 | 63.5 | 63.5 | 50.8 | 4.3 | 3.3 | 575 | 1060 | 59000 | 108000 | — | — | 93787 | 93126 | 235 | 216 | 288 | 306 | 4.3 | 3.3 | 75.8 | 0.52 | 1.1 | 0.63 | 18.2 |
