Tapered roller thrust bearing TFD type bore 120-900mm

Back

Overall dimensions（mm)					Rated load(KN)		Bearing code	Size（mm)		Regarding Installation Dimensions（mm）				Weight(kg)
d	D	T	γ₁(minimum)	γ₂(minimum)	C_a	C_0a	Bearing code	S_W	d₁	d_a	d_a	γ_a（maximum）	γ_b(maximum）	(Reference)
900	1180	220	2	6	4450	29000	900TFD1101	48	990	955	1005	2	5	614
670	900	230	3	6	3700	20100	670TFD9001	50	725	700	740	2.5	5	398
600	910	290	6	6	5200	26500	600TFD9101	70	680	660	696	5	5	650
550	760	230	5	2	3200	15600	550TFD7602	50	590	574	596	4	2	303
550	760	230	2	5	3000	14400	550TFD7601	50	610	576	622	2	4	303
530	710	218	2	3	2500	12700	530TFD7101	57	575	555	583	2	2.5	233
470	720	200	2	4	3200	17800	470TFD7201	40	535	508	545	2	3	285
460	680	155	2	4	2450	14000	460TFD6801	30	510	496	520	2	3	186
450	645	155	4	4	2280	12900	450TFD6401	38	490	472	500	3	3	159
440	660	155	3	5	2430	14400	440TFD6601	35	505	485	517	2.5	4	180
420	620	170	1.5	3	2460	13100	420TFD6201	35	465	450	473	1.5	2.5	169
380	560	130	1.5	3	1470	8650	380TFD5601	32	430	410	438	1.5	2.5	105
350	540	135	3	3	1790	10200	350TFD5401	30	400	385	408	2.5	2.5	109
350	409	130	1.1	3	1350	6600	350TFD4901	30	390	375	398	1	2.5	73.2
320	470	130	1.1	3	1290	6400	320TFD4701	30	350	335	358	1	2.5	73.8
320	440	108	1.5	3	985	5000	320TFD4401	26	355	344	363	1.5	2.5	47.2
300	420	100	1.5	1.5	935	5050	300TFD4201	23	330	321	335	1.5	1.5	41.4
260	360	92	1	2	620	3050	260TFD3601	20	285	273	290	1	2	27.3
250	380	100	1.1	1.1	1010	5100	250TFD3801	22	275	264	280	1	1	39.2
240	320	96	0.6	2.1	565	2550	240TFD3201	22	256	249	262	0.6	2	20.6
