| Overall dimensions（mm) | Size（mm) | Recommended lubricating grease | Contact angle (degrees) | Rated speed min-1 | Bearing code | Rated dynamic load Ca | Extreme axial directionload | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | γ(minimum) | γ1(minimum) | d1 | D2 | d1 | D2 | Filling amount (cc) | Grease lubrication | Single column bears load DF, DB (N) | Double row load-bearing capacity DT, DF, DBD DFF, DBB (N) | Three columns bear the load DTD,DFT,DBT（N) | Single column bears load DF, DB (N) | Double row load-bearing capacity DT, DF, DBD DFF, DBB (N) | Three columns bear the load DTD,DFT,DBT（N) | ||
| 120 | 260 | 55 | 3 | 1.1 | 153 | 189.3 | 190.7 | 223.5 | 170 | 55 | 1500 | 120TAC03CMC | 430000 | 700000 | 930000 | 295000 | 590000 | 885000 |
| 100 | 215 | 47 | 3 | 1.1 | 122.5 | 156.9 | 158.1 | 188.1 | 120 | 55 | 1900 | 100TAC03CMC | 365000 | 595000 | 795000 | 231000 | 460000 | 690000 |
| 80 | 170 | 39 | 2.1 | 1.1 | 94 | 118.5 | 131.5 | 152.5 | 82 | 50 | 2400 | 80TAC03AM | 274000 | 445000 | 590000 | 238000 | 475000 | 715000 |
| 60 | 130 | 31 | 2.1 | 1.1 | 72.1 | 89.8 | 100.2 | 119.4 | 54 | 50 | 3100 | 60TAC03AT85 | 196000 | 320000 | 425000 | 152000 | 305000 | 455000 |
| 55 | 120 | 29 | 2 | 1 | 67.1 | 82.7 | 92.3 | 110.1 | 32 | 50 | 3400 | 55TAC03AT85 | 171000 | 278000 | 370000 | 133000 | 266000 | 400000 |
| 50 | 110 | 27 | 2 | 1 | 60.3 | 75.6 | 84.5 | 100.9 | 27 | 50 | 3700 | 50TAC03AT85 | 150000 | 243000 | 325000 | 116000 | 232000 | 350000 |
| 45 | 110 | 27 | 2 | 1 | 60.3 | 75.6 | 84.5 | 100.9 | 27 | 50 | 3700 | TAC45-2T85 | 150000 | 243000 | 325000 | 116000 | 232000 | 350000 |
| 45 | 100 | 25 | 1.5 | 1 | 55.8 | 68.6 | 76.4 | 91 | 19 | 50 | 4100 | 45TAC03AT85 | 120000 | 195000 | 259000 | 91500 | 183000 | 274000 |
| 40 | 90 | 23 | 1.5 | 1 | 49.7 | 61.4 | 68.6 | 81.9 | 15 | 50 | 4600 | 40TAC03AT85 | 102000 | 166000 | 220000 | 75500 | 151000 | 226000 |
| 35 | 90 | 23 | 1.5 | 1 | 49.7 | 61.4 | 68.6 | 81.9 | 15 | 50 | 4600 | TAC35-2T85 | 102000 | 166000 | 220000 | 75500 | 151000 | 226000 |
| 25 | 52 | 15 | 1 | 0.6 | 30.5 | 36.6 | 40.4 | 47.4 | 3 | 50 | 7700 | 25TAC02AT85 | 33500 | 54500 | 72000 | 22700 | 45500 | 68000 |
| 15 | 35 | 11 | 0.6 | 0.3 | 19.5 | 23.5 | 26.5 | 31.9 | 0.98 | 50 | 12000 | 15TAC02AT85 | 18800 | 30500 | 40500 | 11500 | 22900 | 34500 |
